Description

Jiangsu Yawei Chuangkeyuan Laser Equipment Co., Ltd. (Hereinafter referred to as “YAWE-CKY”) head-quarter located in Wuxi City. The company was founded in 2008 and it is a wholly owned subsidiary of Jiangsu Yawei Machine Tool Co., Ltd.

As a sub-brand of Yawei, YAWEI-CKY is a high-tech enterprise specializing in R&D, manufacture and sales of 2D and 3D laser processing equipments. Positioned at the system integration and technical services of laser equipment, YAWEI-CKY provides laser cutting system, laser welding system, laser cladding system and laser quenching system. Established long-term and stable interaction and cooperation with research institutes such as Suzhou University and Jiangnan University, YAWEI-CKY can provide users with complete laser processing solutions and corresponding supporting facilities, which are widely used in rail transit, automobile and parts, engineering machines, ships, instrumentation, measuring tools, electronic communication, aerospace, petrochemical, and pharmaceutical &food packaging industry and other industries.

Product Detail
Item Unit TFG-6020
Processing range mm Round Tube Ø20~Ø220 / Square Tube 20 ~ 155
Max. tube length mm 6050
X axis stroke mm 320
Z axis stroke mm 350
X axis positioning speed m/min 60
Y axis positioning speed m/min 100
X axis acceleration G 1
Y axis acceleration G 1
W axis rotation speed rad/mi 100
W axis rotation acceleration rad.s2 60
Positioning accuracy mm ±0.03
Re-Positioning accuracy mm ±0.03
Overall dimensions ( L x W X H) mm 13200 x 2800 x 2900
Power of laser Source kW 1500 ~ 3000

*Note: The Specifications and information above-mentioned may be changed without prior notice. For more details, please contact marketing@electronicahitech.com
